frame
6061 alloy, hydro formed t6 aluminium, multi butted, internal cable routing with bbx, custom whyte dropouts and integrated kickstand mount
fork
sr suntour nex hlo 63mm travel, hydro lockout
rear shock
n/a
headset
feimin h807b, semi integrated, 1 1/8" lower 1 1/2 lower caged bearings
rear hub
alloy, cup & cone, double seal, 32 hole
front hub
alloy, cup & cone, double seal, 32 hole
spokes
2.0mm, pg, black stainless, brass nipples
rims
whyte 23 x 700c, 32 hole
tyre
schwalbe road cruiser tour, 700 x 40c, green compound, k-guard puncture protection
shift levers
shimano altus sl-m2010, 9 speed
front mech
shimano altus fd-m370
rear mech
shimano altus rd-m2000-sgs, 9 speed
weight
13.8 kg
cassette
shimano cs-hg-200, 11-36, 9 speed
chain
sunrace, 9 speed
crankset
shimano fc-m210-2, double 46-30, 9 speed
bottom bracket
sealed cartridge bearings, 68mm
seatpost
whyte 6061 alloy, 12mm offset, 30.9mm x s/m 350mm, l/xl 400mm, 2 bolt clamp
saddle
whyte custom
handlebar
whyte 6061 alloy, 25mm rise, 31.8mm, 620mm wide
stem
whyte alloy, +6 degree, 70mm
grips
whyte custom dual density lock-on
brakes front
tektro hd-m275, hydraulic, 160mm rotor
brakes rear
tektro hd-m275, hydraulic, 160mm rotor, internal routing
brake levers
tektro hd-m275
pedals
fibre reinforced composite platform
