FRAME
6061 alloy, Single Chainring (SCR) aluminium front triangle with tapered head tube, ISCG 2 guide mounts, alloy symmetrical SCR rear triangle, Shape.it Link and 148mm Boost dropouts
CHAIN
SRAM GX, 12 speed
FORK
RockShox Lyrik Ultimate RC2 29in, 160mm travel, 44mm offset, DebonAir+ with ButterCups, Charger 3 RC2 damper, Fast Black coating, tapered steerer, 110mm x 15mm Boost, Maxle Ultimate
CRANKSET
SRAM GX, Direct Mount 32T chainring, DUB, 165mm
REAR SHOCK
RockShox Super Deluxe Ultimate RC2T, DebonAir+, Fast Black coating, adjustable rebound, two position compression adjustment
BOTTOM BRACKET
SRAM DUB, BSA, 73mm
HEADSET
FSA No. 57E Orbit ZS, 1 1/2in lower and 1 1/8in upper sealed cartridge bearings
SEATPOST
Whyte drop.it Post II Adjust, 30.9mm (sizes M/L 140-170mm travel; size XL 170-200mm travel), MMX remote lever
REAR HUB
Alloy, double sealed cartridge bearings, 12mm x 148mm Boost spacing, nine degree Micro Engagement, four pawl, XD Driver, 32 hole
SADDLE
Whyte Custom, dual density, triple panel design
FRONT HUB
Alloy, double sealed cartridge bearings, 15mm x 110mm Boost spacing, 31mm torque caps, 32 hole
HANDLEBAR
Whyte Custom 6061 alloy, 20mm rise, 35mm bar bore, 800mm wide
SPOKES
DT Swiss New Champion 2.0mm, black stainless, brass nipples
RIMS
Race Face AR-30, offset, 30mm wide, sleeved joint, tubeless ready, 32 hole
TYRE
Maxxis Assegai TR 29in x 2.5in 60TPI, EXO sidewall protection, 3C Maxx Terra, front; Maxxis Minion DHR II TR 29in x 2.4in WT 120TPI, EXO+ sidewall protection, Dual Compound, rear
BRAKES FRONT
SRAM Code R, four piston hydraulic, sintered metal pads, 200mm diameter disc rotor
SHIFT LEVERS
SRAM GX Eagle Trigger MMX, 12 speed
BRAKES REAR
SRAM Code R, four piston hydraulic, sintered metal pads, 200mm diameter disc rotor
FRONT MECH
N/A
BRAKE LEVERS
SRAM Code R, MMX
REAR MECH
SRAM GX Eagle, 12 speed
PEDALS
Fibre reinforced composite platform
WEIGHT
TBC
