FRAME
Spark RC Carbon HMF, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
FORK
FOX 34 SC Float Performance Air Grip, 3-Modes / Kabolt 15x110mm axle / 44mm offset / tapered steerer, Reb. Adj. / Lockout / 120mm travel
REAR SHOCK
FOX NUDE 5 EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, DPS / Reb. Adj. / Travel 120-80-Lockout / T165X45mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology, 3 Suspension modes
REAR DERAILLEUR
SRAM GX Eagle AXS 12 Speed, Wireless Electronic Shift System
SHIFTERS
SRAM GX Eagle AXS Rocker Controller
CRANKSET
SRAM GX Eagle DUB, 55mm CL / 32T
BB-SET
SRAM DUB PF 92 MTB Wide / shell 41x92mm
CHAIN
SRAM CN GX Eagle
CASSETTE
SRAM XG1275 / 10-52 T
BRAKES
Shimano XT M8100 Disc
ROTOR
Shimano SM-RT76 / 6 Bolt / 180/F and 160/R
HANDLEBAR
Syncros Fraser iC SL XC Carbon, -12° rise / back sweep 8° / 740mm, Syncros Performance XC lock-on grips
SEATPOST
FOX Transfer SL Performance Dropper Post, 31.6mm / S size 75mm / M, L & XL size 100mm, SEATSyncros Belcarra Regular 1.5, Titanium rails
HEADSET
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
WHEELSET
Syncros Silverton 2.0-30 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim / 28H / XD Driver, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
FRONT TIRE
Maxxis Rekon Race / 29x2.4" / 120TPI Foldable Bead, Tubeless Ready / EXO
REAR TIRE
Maxxis Rekon Race / 29x2.4" / 120TPI Foldable Bead, Tubeless Ready / EXO
EXTRAS
SRAM AXS Powerpack
ACCESSORIES
Transport Axle
APPROX WEIGHTS IN KG
11.6 (Tubeless setup)
APPROX WEIGHTS IN LBS
25.57 (Tubeless setup)
MAX. SYSTEM WEIGHT
128kg
