Frame
Genius Carbon HMF Mainframe with Alloy 6061 Swingarm, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork
FOX 36 Float Rhythm Air Grip, 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 160mm travel
Rear Shock
FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 150-100-Lockout / T185X55mm
Remote System
SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes
Rear Derailleur
Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
Shifters
Shimano Deore SL-M6100-IR / Rapidfire Plus, Ispec EV clamp
Crankset
Shimano SLX FC-M7120-1 / Hollowtech 2, 55mm CL / 32T
Chainguide
SCOTT custom
BB-Set
Shimano BB-MT500 / shell 41x92mm
Chain
Shimano Deore CN-M6100
Cassette
Shimano Deore CS-M6100-12 / 10-51 T
Brakes
Shimano Deore M6120 4 Piston Disc
Rotor
Shimano SM-RT64 CL / 203/F and 180/R
Handlebar
Syncros Hixon 1.5 Alloy 7050, Size S & M 15mm rise / Size L & XL 25mm rise, back sweep 8° / 780mm, Syncros Endurance lock-on grips
H'stem
Syncros AM 1.5, Syncros Cable Integration System, 4° rise / 7050 Alloy / 31.8mm / 1 1/8"
Seatpost
Syncros Duncan Dropper Post 1.5, 31.6mm / S size 140mm / M size 160mm / L size 170mm / XL size 200mm
Seat
Syncros Tofino 2.0 Regular, CRMO rails
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Hub (Front)
Formula CL-811 / 15x110mm
Hub (Rear)
Formula CL-148M / 12x148mm
Spokes
Stainless Black 15G / 1.8mm
Rims
Syncros X-30S / 32H / 30mm / Sleeve Joint, Tubeless ready
Front Tire
Maxxis Dissector / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
Rear Tire
Maxxis Dissector / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
Extras
Syncros Fork Fender
Approx weights in KG
14.8 (Tubeless setup)
Approx weights in LBS
32.63 (Tubeless setup)
Max. System Weight
128kg
