FRAME
Carbon HMX Integrated Suspension Technology Flex Pivot / Adjustable head angle Syncros Cable Integration System TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
TRAVEL
Front: 130mm / Rear: 130mm
FORK
FOX 34 Float Factory Air / Kashima FIT4 3-Modes with low Speed adj. / Kabolt 15x110mm axle / 44mm offset Tapered steerer / Lockout / Reb. Adj. 130mm travel
REAR SHOCK
FOX NUDE 5T Factory EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Custom large Air volume / DPS / Kashima / Reb. Adj. Travel 130-90-Lockout / T165X45mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology Suspension & Dropper Remote 3 Suspension modes
DRIVE UNIT
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
BATTERY
TQ Internal 360Wh + Range Extender 160Wh
DISPLAY
TQ HPR Bluetooth / ANT+ / Dedicated Smartphone app
CHARGER
TQ 100-240V-4A
REAR DERAILLEUR
SRAM XX Eagle AXS Transmission 12 Speed Wireless Electronic Shift System
SHIFTERS
SRAM AXS Pod Ultimate Controller
CRANKSET
FSA Carbon crankset / 175mm / 34T
CHAINGUIDE
e*thirteen / e*spec Slider
CHAINRING
Scott custom spider / SRAM Eagle Transmission 34T chainring
CHAIN
SRAM CN XX Eagle Transmission
CASSETTE
SRAM XX Eagle XS 1297 Transmission 10-52
BRAKES
Shimano XTR M9120 4 Piston Disc
ROTOR
Front: RT-MT900 CL 180mm / Rear: RT-EM910 CL 180mm
HANDLEBAR
Syncros Fraser iC SL DC Carbon 0° rise / back sweep 8° / mini Rise / 760mm Syncros Performance XC lock-on grips
SEATPOST
FOX Transfer Factory Dropper Post Kashima 31.6mm / S size 125mm / M size 140mm L ize 150mm / XL size 175mm SEAT Syncros Tofino Regular 1.0 Carbon rails
HEADSET
Syncros - Acros Angle adjust & Cable Routing HS System Stainless +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
WHEELSET
Syncros Silverton SL2-30 CL full Carbon F: 15x110mm R: 12x148mm / 30mm Tubeless ready rim DT Swiss 240 Ratchet EXP 36 / XD Driver SRAM TyreWiz / Syncros SL Axle w/Removable Lever with 6mm Allen, T30 and T25 Tools
FRONT TIRE
Schwalbe Wicked Will 29x2.4" EVO Super Race / TLE / 67EPI / Addix Speed Soft
REAR TIRE
Schwalbe Wicked Will 29x2.4" EVO Super Race / TLE / 67EPI / Addix Speed Grip
EXTRAS
SRAM AXS Powerpack Syncros Fork Fender
ACCESSORIES
Syncros Eco Sealant Transport Axle
APPROX WEIGHTS IN KG
15.5 (Tubeless setup)
APPROX WEIGHTS IN LBS
34.17 (Tubeless setup)
MAX. SYSTEM WEIGHT
110 kg
