| Material
Carbon C Our C Carbon frames use the same proprietary processes of the highest spec CC Carbon frames to match the same legendary strength and stiffness standards. But the use of a different grade of carbon material results in a minimal weight gain. | Material
Carbon C Our C Carbon frames use the same proprietary processes of the highest spec CC Carbon frames to match the same legendary strength and stiffness standards. But the use of a different grade of carbon material results in a minimal weight gain. | Material
Carbon C Our C Carbon frames use the same proprietary processes of the highest spec CC Carbon frames to match the same legendary strength and stiffness standards. But the use of a different grade of carbon material results in a minimal weight gain. | Material
Carbon CC CC denotes our highest grade carbon fiber frames. Use of the very best materials in the composite results in the lightest, best handling bikes. CC level bikes are also specced with the best wheels, drivetrains and suspension on these models. | Material
Carbon CC CC denotes our highest grade carbon fiber frames. Use of the very best materials in the composite results in the lightest, best handling bikes. CC level bikes are also specced with the best wheels, drivetrains and suspension on these models. Learn More | |
| Travel
150mm | Travel
150mm | Travel
150mm | Travel
150mm | Travel
150mm | |
| Wheel Size
MX | Wheel Size
MX | Wheel Size
MX | Wheel Size
MX | Wheel Size
MX | |
| Rear Shock
FOX Float Performance, 210x55 or Fox Float DPS Performance, 210x55 | Rear Shock
RockShox Super Deluxe Select+, 210x55 | Rear Shock
RockShox Super Deluxe Select+, 210x55 | Rear Shock
RockShox Super Deluxe Ultimate, 210x55 | Rear Shock
RockShox Super Deluxe Ultimate, 210x55 | |
| Fork
RockShox Lyrik Base, 160mm | Fork
RockShox Lyrik Select+, 160mm | Fork
RockShox Lyrik Select+, 160mm | Fork
RockShox Lyrik Ultimate, 160mm | Fork
RockShox Lyrik Ultimate, 160mm | |
| Rear Derailleur
SRAM NX Eagle, 12spd | Rear Derailleur
SRAM GX Eagle, 12spd | Rear Derailleur
SRAM GX Eagle AXS T-Type, 12spd | Rear Derailleur
SRAM X0 Eagle AXS T-Type, 12spd | Rear Derailleur
SRAM XX Eagle AXS T-Type, 12spd | |
| Right Shifter
SRAM NX | Right Shifter
SRAM GX Eagle Single Click, 12spd or SRAM X01 Eagle Single Click, 12spd | Right Shifter
SRAM AXS Pod Bridge | Right Shifter
SRAM AXS Pod Bridge | Right Shifter
SRAM AXS Pod Ultimate Bridge | |
| Cassette
SRAM PG1230, 12spd, 11-50t | Cassette
SRAM XG1275 Eagle, 12spd, 10-50t or SRAM XG1275 Eagle, 12spd, 10-52 | Cassette
SRAM GX Eagle T-Type, 10-52t | Cassette
SRAM X0 Eagle T-Type, 10-52t | Cassette
SRAM XX Eagle T-Type, 10-52t | |
| Chain
SRAM NX Eagle, 12spd | Chain
SRAM GX Eagle, 12spd or SRAM X01 Eagle, 12spd | Chain
SRAM GX Eagle T-Type, 12spd | Chain
SRAM X0 Eagle T-Type, Flattop, 12spd | Chain
SRAM XX Eagle T-Type, Flattop, 12spd | |
| Chainguide
OneUp Chainguide | Chainguide
OneUp Chainguide | Chainguide
OneUp Chainguide | Chainguide
OneUp Chainguide | Chainguide
OneUp Chainguide | |
| Headset
FSA IS-2/47/42 ACB or Cane Creek 10 IS Integrated | Headset
Cane Creek 40 IS Integrated Headset | Headset
Cane Creek 40 IS Integrated Headset | Headset
Cane Creek 40 IS Integrated Headset | Headset
Chris King DropSet 3 Integrated Headset | |
| Rear Tire
Maxxis Minion DHR II 27.5"x2.4", 3C MaxxTerra, EXO+ | Rear Tire
Maxxis Minion DHR II 27.5"x2.4", 3C MaxxTerra, EXO+ | Rear Tire
Maxxis Minion DHR II 27.5"x2.4", 3C MaxxTerra, EXO+ | Rear Tire
Maxxis Minion DHR II 27.5"x2.4", 3C MaxxTerra, EXO+ | Rear Tire
Maxxis Minion DHR II 27.5"x2.4", 3C MaxxTerra, EXO+ | |
| Front Tire
Maxxis Minion DHF 29"x2.5"WT, 3C MaxxGrip, EXO | Front Tire
Maxxis Minion DHF 29"x2.5"WT, 3C MaxxGrip, EXO | Front Tire
Maxxis Minion DHF 29"x2.5"WT, 3C MaxxGrip, EXO | Front Tire
Maxxis Minion DHF 29"x2.5"WT, 3C MaxxGrip, EXO | Front Tire
Maxxis Minion DHF 29"x2.5"WT, 3C MaxxGrip, EXO | |
| Front Hub
SRAM MTH 716, 15x110, Torque Cap, 6-Bolt 32h | Front Hub
DT Swiss 370, 15x110, Torque Cap, 6-Bolt, 28h | Front Hub
DT Swiss 370, 15x110, Torque Cap, 6-Bolt, 28h | Front Hub
Industry Nine 1/1, 15x110, Torque Cap, 6-Bolt, 28h | Front Hub
Industry Nine Hydra, 15x110, Torque Cap, 6-Bolt, 28h | |
| Front Rim
WTB ST i30 TCS 2.0 29" | Front Rim
RaceFace AR Offset 30, 29" | Front Rim
Reserve 30|SL AL 6069 29" | Front Rim
Reserve 30|HD 29" The Reserve 30|HD is specially designed for aggressive trail riding. They feature a 30mm width for use with 2.5 tires and a redesigned inner rim bed that takes the hassle out of seating new tires. The Reserve 30|HD is the ultimate mountain bike rim. | Front Rim
Reserve 30|HD 29" The Reserve 30|HD is specially designed for aggressive trail riding. They feature a 30mm width for use with 2.5 tires and a redesigned inner rim bed that takes the hassle out of seating new tires. The Reserve 30|HD is the ultimate mountain bike rim. | |
| Rear Hub
SRAM MTH 746, 12x148, HG, 6-Bolt, 32h | Rear Hub
DT Swis 370, 12x148, XD, 6-Bolt, 36t, 28h | Rear Hub
DT Swis 370, 12x148, XD, 6-Bolt, 36t, 28h | Rear Hub
Industry Nine 1/1, 12x148, XD, 6-Bolt, 28h | Rear Hub
Industry Nine Hydra, 12x148, XD, 6-Bolt, 28h | |
| Rear Rim
WTB ST i30 TCS 2.0 27.5" | Rear Rim
RaceFace AR Offset 30, 27.5" | Rear Rim
Reserve 30|SL AL 6069 27.5" | Rear Rim
Reserve 30|HD 27.5" The Reserve 30|HD is specially designed for aggressive trail riding. They feature a 30mm width for use with 2.5 tires and a redesigned inner rim bed that takes the hassle out of seating new tires. The Reserve 30|HD is the ultimate mountain bike rim. | Rear Rim
Reserve 30|HD 27.5" The Reserve 30|HD is specially designed for aggressive trail riding. They feature a 30mm width for use with 2.5 tires and a redesigned inner rim bed that takes the hassle out of seating new tires. The Reserve 30|HD is the ultimate mountain bike rim. | |
| Front Rotor
Avid Centerline, 200mm | Front Rotor
Avid Centerline, 200mm | Front Rotor
SRAM HS2 200mm | Front Rotor
SRAM HS2 200mm | Front Rotor
SRAM HS2 200mm | |
| Rear Rotor
Avid Centerline, 200mm | Rear Rotor
Avid Centerline, 200mm | Rear Rotor
SRAM HS2 200mm | Rear Rotor
SRAM HS2 200mm | Rear Rotor
SRAM HS2 200mm | |
| Brakes
SRAM DB8 | Brakes
SRAM Code R | Brakes
SRAM Code Bronze Stealth | Brakes
SRAM Code Silver Stealth | Brakes
Code Ultimate Stealth | |
| Crankset
Praxis eTor AL, 104BCD, 165mm | Crankset
Praxis eTor AL, 104BCD, 165mm | Crankset
Praxis eTor AL, 104BCD, 165mm | Crankset
Praxis eTor AL, 104BCD, 165mm | Crankset
Praxis eTor AL, 104BCD, 165mm | |
| Handlebars
e13 TRS Base | Handlebars
Burgtec Alloy Bar | Handlebars
Santa Cruz 35 Carbon Bar, 800mm | Handlebars
Santa Cruz 35 Carbon Bar, 800mm | Handlebars
Santa Cruz e35 Carbon Bar, 800mm | |
| Stem
e.13 Base | Stem
Burgtec Enduro MK3, 42mm | Stem
Burgtec Enduro MK3, 42mm | Stem
Burgtec Enduro MK3, 42mm | Stem
Burgtec Enduro MK3 Machined, 42mm | |
| Saddle
WTB Silverado Medium, CroMo | Saddle
WTB Silverado Medium, CroMo | Saddle
WTB Silverado Medium, CroMo | Saddle
WTB Silverado Medium, Ti | Saddle
WTB Silverado Medium, Ti | |
| Seatpost
SDG Tellis Dropper, 31.6 | Seatpost
OneUp V2 Dropper Post, 31.6 or RockShox Reverb, 31.6 | Seatpost
OneUp V2 Dropper Post, 31.6 | Seatpost
OneUp V2 Dropper Post, 31.6 | Seatpost
RockShox Reverb AXS, 31.6 | |
| Grips
Santa Cruz Bicycles House Grips or Burgtec Bartender Pro Grip Minnar | Grips
Santa Cruz Bicycles House Grips or Burgtec Bartender Pro Grip Minnar | Grips
Santa Cruz Bicycles House Grips or Burgtec Bartender Pro Grip Minnar | Grips
Santa Cruz Bicycles House Grips or Burgtec Bartender Pro Grip Minnar | Grips
Santa Cruz Bicycles House Grips or Burgtec Bartender Pro Grip Minnar | |
| Battery
FAZUA 430 Wh Integrated Battery | Battery
FAZUA 430 Wh Integrated Battery | Battery
FAZUA 430 Wh Integrated Battery | Battery
FAZUA 430 Wh Integrated Battery | Battery
FAZUA 430 Wh Integrated Battery | |
| Drive Unit
FAZUA RIDE60 The FAZUA RIDE 60 drive unit holds the motor, gearbox and sensors. It’s extremely light, powerful, compact and nearly silent. It produces 60 Nm of torque power and is capable of up to 450W, which makes it stronger than other “mid-power” or “lightweight” systems. | Drive Unit
FAZUA RIDE60 The FAZUA RIDE 60 drive unit holds the motor, gearbox and sensors. It’s extremely light, powerful, compact and nearly silent. It produces 60 Nm of torque power and is capable of up to 450W, which makes it stronger than other “mid-power” or “lightweight” systems. | Drive Unit
FAZUA RIDE60 The FAZUA RIDE 60 drive unit holds the motor, gearbox and sensors. It’s extremely light, powerful, compact and nearly silent. It produces 60 Nm of torque power and is capable of up to 450W, which makes it stronger than other “mid-power” or “lightweight” systems. | Drive Unit
FAZUA RIDE60 The FAZUA RIDE 60 drive unit holds the motor, gearbox and sensors. It’s extremely light, powerful, compact and nearly silent. It produces 60 Nm of torque power and is capable of up to 450W, which makes it stronger than other “mid-power” or “lightweight” systems. | Drive Unit
FAZUA RIDE60 The FAZUA RIDE 60 drive unit holds the motor, gearbox and sensors. It’s extremely light, powerful, compact and nearly silent. It produces 60 Nm of torque power and is capable of up to 450W, which makes it stronger than other “mid-power” or “lightweight” systems. | |
| Battery Charger
FAZUA Charger | Battery Charger
FAZUA Charger | Battery Charger
FAZUA Charger | Battery Charger
FAZUA Charger | Battery Charger
FAZUA Charger | |
